Project StadtLärm

A platform to visualise, analyse and avoid an excess of urban noise

Noise affects the quality of life

City residents are exposed to numerous, strongly fluctuating noise pollution caused by major and sporting events, construction measures or individual road users. In the StadtLärm project, a system was therefore developed with which noise-space models can be visualised and processed three-dimensionally in a novel application and measurement data can be assigned to a specific event.

Complete solution for novel noise monitoring – first field test in Jena

The system has been tested in the city of Jena in a field test since spring 2018. It can be used to record sound-related, anonymised sensor data over a large area and continuously. Noise-space models are processed in a novel application and visualised three-dimensionally in maps of the city of Jena and via diagrams. The measurement data can be assigned to a specific event, such as a registered concert in the city centre.

Municipal authorities can view not only noise levels but also noise events classified by the system according to their type in a web-based application and assess noise sources much better. For this purpose, temporally and spatially resolved noise data can be consulted both in real time and retrospectively over specific and longer periods of time. In addition, future noise situations can be predicted from past noise events.

The classification of sound events was developed by the project partner Fraunhofer IDMT. The data supplier for the application is a platform with noise sensors developed by Bischoff Elektronik GmbH and a central "data hub" in the form of a so-called MQTT broker. This forms the interface to algorithmic evaluations of the Fraunhofer IDMT and to the StadtLärm application, which was developed by the partner Software-Service John.

IMMS contribution – the data hub

IMMS developed the basic software platform for the noise sensors, including audio data acquisition, and integrated the audio data pre-processing of Fraunhofer IDMT. IMMS solved the communications via the broker and designed the communications architecture as a whole; i.e. defined the communications structures and messages, configured and maintained the broker and created a central administration component for the entire system. In addition, IMMS integrated variable environmental sensor technology to increase the platform's usefulness.

MDR Wissen extended the StadtLärm project to Central Germany

Together with the project partners, MDR Wissen explored different sources of noise in its broadcasting area and therefore called on people in Central Germany to report sources of noise to MDR Wissen.

Acronym / Name:

StadtLärm / Development of a Decision Support and Noise Monitoring System for Urban Noise Management Tasks

Duration:2016 – 2018

Application:

Environmental monitoring and smart city applications|Environmental sensors| outdoor sensors| sensor networks| acoustics| sensor platform| communications| IoT

Research field:Smart distributed measurement and test systems


Related content

Reference

Dirk-Hendrik John, Software-Service John GmbH

“From our point of view, the design IMMS came up with for the architecture was in itself convincing. Further, we were impressed by its support in integrating our application with the MQTT standard. Both during the ongoing joint field test in Jena and during the entire project period, IMMS staff were always readily available with prompt support if questions or problems arose.”
Reference
  • Urban Noise Monitoring in the StadtLärm Project – a Field Report

    Jakob Abeßer1. Marco Götze2. Tobias Clauß1. Dominik Zapf1. Christian Kühn1. Hanna Lukashevich1. Stephanie Kühnlenz3. Stylianos Mimilakis1.

    Detection and Classification of Acoustic Scenes and Events (DCASE) 2019, 25 - 26 October 2019, New York City, USA, DOI: doi.org/10.33682/s9w3-5341

    1Fraunhofer Institute for Digital Media Technology (IDMT), Ilmenau, Germany. 2IMMS Institut für Mikroelektronik- und Mechatronik-Systeme gemeinnützige GmbH, 98693 Ilmenau, Germany. 3Software-Service John GmbH, Ilmenau, Germany.
  • Ein Blick in die Zukunft: Der Weg zur integrierten Systemlösung

    Tino Hutschenreuther1.

    Technologietag 2018 des Fraunhofer IDMT, „Akustische Verfahren zur Qualitätsprüfung – Berührungslos, zerstörungsfrei & sicher integriert“, 9. Oktober 2018, comcenter Brühl, Erfurt

    1IMMS Institut für Mikroelektronik- und Mechatronik-Systeme gemeinnützige GmbH, 98693 Ilmenau, Germany.
  • A Distributed Sensor Network for Monitoring Noise Level and Noise Sources in Urban Environments

    Jakob Abeßer1. Robert Gräfe1. Christian Kühn1. Tobias Clauß1. Hanna Lukashevich1. Marco Götze2. Stephanie Kühnlenz3.

    2018 IEEE 6th International Conference on Future Internet of Things and Cloud (FiCloud), Barcelona, 6-8 August 2018, pp. 318-324. DOI: doi.org/10.1109/FiCloud.2018.00053

    1Fraunhofer Institute for Digital Media Technology (IDMT), Ilmenau, Germany. 2IMMS Institut für Mikroelektronik- und Mechatronik-Systeme gemeinnützige GmbH, 98693 Ilmenau, Germany. 3Software-Service John GmbH, Ilmenau, Germany.
  • An Open Platform for Distributed Urban Noise Monitoring

    Marco Goetze1. Rolf Peukert1. Tino Hutschenreuther1. Hannes Toepfer2.

    2017 25th Telecommunication Forum (TELFOR), 21-22 November 2017, Belgrade, Serbia, pp. 1-4, DOI: doi.org/10.1109/TELFOR.2017.8249339

    1IMMS Institut für Mikroelektronik- und Mechatronik-Systeme gemeinnützige GmbH, 98693 Ilmenau, Germany. 2Ilmenau University of Technology.
